Step-by-Step Installation Guide

Power Off: Ensure the power supply is turned off before starting installation to avoid electrical hazards.

Mount the Bracket: Attach the provided surface mounting bracket to the wall using appropriate screws‚ ensuring it is level and secure.

Wiring Connections: Connect the live‚ neutral‚ and load wires to the corresponding terminals in the timer switch. Refer to the wiring diagram for correct connections.

Secure the Timer: Mount the timer onto the installed bracket‚ ensuring it clicks securely into place.

Restore Power: Turn the power supply back on and test the timer to ensure proper functionality.

Final Check: Double-check all connections and ensure the timer is properly mounted before operating.

Setting the Clock

Press MODE to access the clock setting. Use HOUR and MIN buttons to set the current time‚ then press ENTER. The day of the week will automatically update once the date is set.

Configuring Time‚ Date‚ and Daylight Saving Time

To configure the time‚ press the MODE button until the clock screen appears. Use the HOUR and MIN buttons to set the current time‚ then press ENTER. Next‚ press MONTH‚ DATE‚ and YEAR to set the current date‚ and press ENTER to save. The day of the week will automatically update once the date is set. For daylight saving time (DST)‚ the display will show “dSt on.” If DST is required‚ press ENTER to enable it; otherwise‚ press DEL to disable it and press ENTER. The timer will automatically adjust for DST if enabled. These settings ensure accurate scheduling and automatic adjustments for seasonal time changes‚ simplifying your experience with the Tork EWZ201 timer.

Programming the Timer

Program the timer by setting ON and OFF schedules using the MODE button. Navigate to the desired settings and press ENTER to save. Use astronomic mode for automatic sunset and sunrise control.

Setting ON and OFF Schedules

To set ON and OFF schedules‚ press the MODE button five times until the display shows all dashes. Use the HOUR and MIN buttons to select the desired time for the OFF schedule. For midnight‚ set the clock to 12:01 AM and ensure the AM/PM setting is correct. Press CH1/CH2 to toggle between channels and select the desired one. Repeat the process to set the ON time. Each channel can have up to 7 ON/OFF events. After setting the desired times‚ press ENTER to save the schedule. The timer will automatically follow the programmed schedule. Ensure all settings are correct before exiting the programming mode. This feature allows for precise control of connected devices‚ optimizing energy usage and convenience.

Using Astronomic Mode for Sunset and Sunrise Control

The Tork EWZ201 features an Astronomic Mode that automatically controls lighting based on sunset and sunrise times. To enable this‚ first set the clock‚ date‚ and daylight saving time. Navigate to the ASTRO mode section (7.0) and enter your location’s latitude. The timer will calculate and adjust ON/OFF times according to local solar events. This mode is ideal for outdoor lighting‚ ensuring lights turn on at sunset and off at sunrise. For example‚ set the timer to “Sunset ON” and “Sunrise OFF” for automatic operation. The device will adjust schedules yearly‚ accounting for daylight saving time if enabled. This feature saves energy and enhances convenience by eliminating manual adjustments. Ensure latitude is accurately entered for precise timing. The Astronomic Mode integrates seamlessly with the timer’s programming‚ offering reliable and efficient control for outdoor lighting systems year-round.

Troubleshooting and FAQs

Address common issues like timer malfunction or incorrect time. Check power supply‚ battery‚ and settings. Refer to the manual for solutions. FAQs cover topics like resetting‚ daylight saving‚ and programming. Contact support for unresolved issues.

Common Issues and Solutions

Common issues with the Tork EWZ201 include the timer not turning loads on/off‚ incorrect time display‚ or the backlight not functioning. For the timer not operating‚ check the power supply‚ circuit connections‚ and ensure the timer is properly programmed. If the time is incorrect‚ sync it with the current time and verify daylight saving settings. For display issues‚ reset the timer by removing and reinstalling the battery. If problems persist‚ consult the manual or contact Tork’s customer support. Ensure the timer is installed by a licensed electrician to avoid safety hazards. Regularly update settings to maintain accuracy‚ especially during daylight saving transitions. Refer to the troubleshooting section in the manual for detailed solutions and guidelines to resolve these issues effectively.

Frequently Asked Questions

How do I set the clock on my Tork EWZ201? Press MODE to access the clock settings‚ then use HOUR and MIN buttons to set the current time‚ and press ENTER to save.

What is Astronomic Mode? Astronomic Mode automatically turns lights on at sunset and off at sunrise‚ using your location’s latitude for accurate timing.

Can I control two different loads independently? Yes‚ the EWZ201 is a 2-channel timer‚ allowing separate schedules for each channel.

How do I enable Daylight Saving Time? After setting the clock and date‚ press ENTER to enable DST. If not needed‚ press DEL to disable it.

Why isn’t my timer turning on the lights? Check if the timer is in AUTO mode‚ verify the schedule‚ and ensure the circuit is properly connected.

How do I reset the timer? Remove the battery‚ wait 10 seconds‚ and reinstall it to reset the timer to factory settings.

Can I program schedules for specific days? Yes‚ use the DAY button to select the desired days for each channel’s schedule.

Is the timer suitable for outdoor use? Yes‚ it is designed for both indoor and outdoor applications‚ with a durable construction for weather resistance.

How do I update the timer’s firmware? Firmware updates are not typically required‚ as the timer’s functionality is fixed. Refer to the manual for any software-related instructions.

What is the maximum load capacity? The timer supports up to 30 Amps‚ suitable for most residential and light commercial applications.
